OUR NEW PRODUCTS


GMS 543
Digital Pressure Indicator (Resistive I/P)
Single Phase Genset Controller
Line Voltage Monitor (LVM)

ABOUT US

Our Vision

Quality, Innovation, Customization and Customer Satisfaction form the bedrock of our vision which has propelled us in our constant endeavors to set new standards of excellence in the industry.




Engine Safety Unit & Genset Controller Manufacturer

Established in 1989 by Mr. Ramesh B Sanghvi, RB Eco Power has carved a special niche for itself in the field of Engine Safety Units, Genset Display Units, Automatic Mains Failure Panels and other Customized Automation Solutions for Engines, Generators etc. Having established itself as an industry leader through quality and innovation, RB Eco Power has also forayed into the field of Solar Solutions & LED Lighting solutions for a wide range of requirements. We are today one of India’s most reputed suppliers for domestic as well as global Engine and Generator Manufacturing units and are on our way there with solar and LED solutions tool.

Our Strengths

Backed by more than 2 decades of extensive industry experience, we at RB Eco Power, pride at our ability to continuously transform ourselves in meeting evolving challenges. Technology combined with innovation has given us the edge to stay ahead of competition making us a trusted name in the industry.
Our skilled and expert engineers harness the true power of R & D at our State of the Art facilities at the Pune Complex to create solutions which meet the most stringent and demanding client aspirations. As a policy our engineers and technicians work closely with client right from the inception stage to provide complete customization that can accurately address the typical specifications and functionalities required by the client.
Our commitment to creating Robust, Reliable and Efficient systems had won us accolades from across the world. Our satisfied and happy customers encourage and help us to strive for greater heights constantly. We have streamlined and well monitored quality assurance channels integrated into our operations which ensure the highest standards every time a product rolls out of our facility.


× Image

GMS 543


Features:

  • Displays RPM, Frequency, Hours
  • Battery operated, available in12VDC & 24VDC models
  • Built in single phase / three phase monitor and protection
  • Integration of all engine and alternator parameters
  • Events Log
  • Mains Voltage Measurement
  • Under voltage/over voltage protection
  • Flexible AMF logic
  • Auto / Manual Modes
  • 8 Digital Inputs
  • 4 Analog Inputs
  • 8 Relay outputs
  • Periodic Start / Stop facility
  • LED Indications for genset status & Alarms

Specifications:

  • Dimension:- 180 x 126 x 51mm
  • Supply:- 8-36 VDC
  • VAC input rating: 450 VAC ( L-N) 750 VAC (L-L)
  • RS 485 communication.


× Image

Digital Pressure Indicator
(Resistive I/P)


Features:

  • Displays Oil pressure
  • Reverse battery protection
  • Short Circuit protection
  • IP65 Protection
  • Complied tests as per standard:
    1. EFT as per IEC 61000 4-4
    2. Surge as per IEC 61000 4-5
    3. Radiated Susceptibility test as per IEC61000 4-3
    4. Radiated emission Test as per CISPR 11/CISPR 22
    5. IP 65 as per IEC 60529
    6. Temperature Test : - 20°C to + 70°C
    7. Vibration : 5G

Specifications:

  • Sensor Type:- Resistive
  • Current Range:- 0-10 Bar
  • Dimensions : Round Dia: 60mm , Depth : 69mm
  • Supply Voltage : 8V-30VDC
  • Operating Temperature: - 20°C to + 70°C


× Image

Single Phase Genset Controller


Features:

  • Manual Start-Stop and auto stop on fault
  • Monitors Genset Parameters monitoring
    1. Battery Voltage
    2. Fuel Level
    3. Single Phase Voltage
    4. Frequency
    5. Engine Run Hour
    6. Digital Input: LOP, Temperature
  • ETR or ETS Genset Start - Stop Operation.
  • Fault Detection & Warning indications
  • Over & Under Voltage Protection

Specifications:

  • Dimensions : 72 x 72 x 112mm
  • Supply Voltage : 8 - 30 VDC
  • VAC Input Rating :- 50 – 320 VAC
  • Five LED Indications.
  • 1Analog Input - Resistive type
  • 2 Digital Input : Oil pressure, Temperature
  • Low Side Relay Output : Start, Stop
  • Genset Single Phase Input.
  • Operating Temperature: - 20°C o + 70°C


× Image

Line Voltage Monitor (LVM)


Features:

  • Single/ Three phase selection
  • Fixed/adjustable under/Over voltage trip settings
  • Two relay output Contacts

Specifications:

  • Dimensions :- 96 X 96 X 72 mm
  • Supply :- 85 – 270 VAC
  • Trip Time Delay :-1-10 secs. (adjustable)
